In the vibrant industrial landscape of Kinshasa, Yoane Steel has established itself as a trusted partner for critical infrastructure projects. We take pride in our role as a leading manufacturer and supplier, specializing in high-performance materials built to withstand the most challenging environments. Our focus here is on the exceptional SA 516 GR.6070N NACE HIC plates, a product engineered for superior resilience and safety in critical applications where reliability is not just a preference, but an absolute necessity.
The composition of these plates is carefully balanced, primarily featuring carbon, manganese, and silicon, with strict controls on impurities like phosphorus and sulfur. This precise chemical recipe is key to achieving the required mechanical properties, including excellent tensile strength and notch toughness, even in low-temperature service. The defining characteristic, however, is their certified HIC resistance, ensuring they remain durable and safe when exposed to environments containing wet hydrogen sulfide, a common and aggressive corrosive element.
| Grade | ASME SA 516 GR.60/70N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.20 | 0.4 | 0.95/1.50 | 0.025 | 0.025 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| 0.18 | 0.4 | 0.95/1.50 | 0.015 | 0.008 | 0.02 (Min) | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength | Yield strength | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 415-550 MPa | 250 MPa | 21 | 25 |
| 485-620 (70-90) | 260 (38) | 17 | 21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-161-430A | EN10028 P265GH | A/SA516 – Grade 60 | DIN 17155 HII |
| BS1501-224-490A/B | EN10028 P355GH | A/SA516 – Grade 70 | – |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.60/70N NACE and HIC Plates in Kinshasa, Congo. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.60/70N NACE and HIC Plates needs!
Because of their specialized toughness and corrosion resistance, these plates are indispensable in building safer, longer-lasting industrial equipment. You will typically find them in the fabrication of pressure vessels, reactors, and storage tanks for the oil and gas industry, particularly in sour service pipelines. They are also crucial for scrubbers and other equipment in petrochemical plants, providing a vital layer of protection against catastrophic failure and ensuring the integrity of critical containment systems for years to come.
Yoane Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Kinshasa, Congo.
