In the heart of Kinshasa, Yoane Steel stands as a trusted partner for industry, providing robust solutions for the most demanding projects. We are proud to supply high-grade materials like DILLIDUR 400V sheets and plates, bringing exceptional strength directly to the fabricators and builders driving progress across Congo. Our commitment goes beyond delivery; we offer reliable support and local expertise, ensuring you have the right material and the right advice to build with confidence and durability.
The DILLIDUR 400V grade is specifically engineered for toughness. Its composition is a fine-tuned balance of elements that give it superior yield strength and impressive hardness. What truly sets it apart, however, is its exceptional abrasion resistance, meaning it stands up remarkably well to constant wear and tear. This combination of mechanical properties makes it a go-to material for situations where both structural integrity and long-lasting performance are non-negotiable priorities.
Item: Dillidur 400V
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : PVDF, PE, HDP, SMP, EP
| C | Si | Mn | P | S | Mo | Ni | Cr | V | Nb | B |
| ≤ 0.20 | ≤ 0.50 | ≤ 1.80 | ≤ 0.025 | ≤ 0.010 | ≤ 0.50 | ≤ 0.80 | ≤ 1.50 | ≤ 0.08 | ≤ 0.05 | ≤ 0.005 |
| Grade | Mechanical Property | Charpy V Impact Test | |||
| DILIDUR 400V | Yield | Tensile | Elongation | Degree | longitudinal |
| Min Mpa | Mpa | Min % | -40 | J | |
| 1000 | 1250 | 10 | 45 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
The real value of DILLIDUR 400V is seen in action, particularly in environments where equipment faces a daily battle against abrasion and impact. You’ll find it expertly used in the linings of heavy-duty dump trucks, in hoppers and chutes that handle abrasive materials, and in machinery for mining and quarrying operations. It’s also ideal for constructing robust containers and any equipment part where reducing downtime for replacements is a key concern, effectively extending the working life of vital assets.
Yoane Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Kinshasa, Congo.
