In the dynamic industrial landscape of Kinshasa, Yoane Steel stands as a trusted partner for robust and reliable materials. We proudly supply the Carbon Steel BS3606 Pipe, a cornerstone for countless construction and engineering projects across Congo. Our commitment is to provide pipes that meet the highest standards of quality and durability, ensuring your infrastructure is built on a foundation of strength. We understand the unique demands of local projects and deliver solutions you can count on.
The composition of this pipe is primarily iron and carbon, creating a fundamental yet incredibly strong material. It’s engineered to possess excellent mechanical properties, including a high tensile strength that allows it to withstand immense pressure and heavy loads without deforming. This inherent toughness, combined with good malleability, makes it a dependable choice for demanding applications where reliability is absolutely essential.
| Dimensions | ASTM, ASME and API |
| Thickness | 50mm to 7.00mm, custom OD and thickness available on request |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Required Length, Custom Size – according to customer’s requirement |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Types | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter | 19.05mm to 127mm |
| Wall Thickness | 0.8mm to 6.0mm |
| Length | 6mtr/ 12mtr or Cut to Length |
| Capacity | 7000 Mt/Month |
|
Grade |
Mfg. Process |
Chemical Composition(%) | ||||||||
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
Others |
||
|
BW320 |
B |
0.16Max |
– |
0.30~0.70 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
ERW320 |
E |
0.16Max |
– |
0.30~0.70 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
ERW360 |
E |
0.17Max |
0.35Max |
0.40~0.80 |
0.040Max |
0.050Max |
– |
– |
– |
– |
|
ERW430 |
E |
0.21Max |
0.35Max |
0.40~1.20 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
S360 |
S |
0.17Max |
0.35Max |
0.40~0.80 |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
S430 |
S |
0.21Max |
0.35Max |
0.40~1.20 |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
SAW430 |
A |
0.25Max |
0.50Max |
1.20Max |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
Grade
| Tensile Test MPa or N/mm2 | Remaks (Similar to JIS) | Possibility Temperature | |
Min Yield point | Tensile Strength | |||
BW320 | 195 | 320~460 | – | |
ERW320 | 195 | 320~460 | – | |
ERW360 | 235 | 360~500 | (STPG370) | |
ERW430 | 195 | 430~570 | (STPG410) | |
S360 | 235 225 215 | 360~550 | (STPG310) | |
S430 | 275 265 255 | 430~570 | (STPG410) | |
SAW430 | 275 265 255 | 430~570 | (STPY400) | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outer Diameter (OD) | Wall Thickness (WT) | Length |
|---|---|---|
| 6mm – 25mm | 1mm – 3mm | Up to 6 meters |
| 26mm – 50mm | 3mm – 6mm | Up to 9 meters |
| 51mm – 150mm | 6mm – 12mm | Up to 12 meters |
| 151mm – 300mm | 12mm – 25mm | Customizable |
| 301mm – 508mm | 25mm – 50mm | Customizable |
Jaxon Steel is a leading manufacturer and exporter of Carbon Steel BS3606 Pipes in Kinshasa, Congo. We offer a vast array of steel solutions, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our diverse product portfolio includes pipes, tubes, flanges, pipe fittings, forged fittings, sheets, and plates. We are the most trusted name for supplying critical industrial applications with superior-quality steel products, built on reliability and excellent service. Our BS3606 Pipes are hard-wearing and high-performance-efficient. Jaxon Steel is here to fulfill all your Carbon Steel BS3606 Pipe requirements.
From the vital water lines running beneath our city to the structural supports in new commercial buildings, the Carbon Steel BS3606 Pipe is an unsung hero. Its primary use is in fluid transport systems, carrying water, oil, and gas across various industries. You’ll also find it forming the backbone of scaffolding, fencing, and mechanical systems. It’s the go-to material for projects that require a perfect balance of cost-effectiveness and unwavering strength, making it indispensable for Kinshasa’s continued growth and development.
Yoane Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Kinshasa, Congo.
