Based in the heart of Kinshasa, Yoane Steel stands as a trusted partner for industry across Congo, dedicated to providing robust and reliable materials for the nation’s growth. We take pride in our role as a premier manufacturer and supplier, with our Carbon Steel BS3601 Pipe representing our commitment to quality and durability. This product is engineered to meet the rigorous demands of various applications, ensuring that your projects are built on a foundation of strength and dependability that you can count on for the long term.
The composition of this pipe is a careful balance of carbon and manganese, creating a material known for its solid performance. Its mechanical properties are defined by a noteworthy tensile strength and a dependable yield point, which together ensure it can handle significant pressure and structural loads. This combination results in a pipe that is not only strong but also offers good malleability, making it a practical and resilient choice for a wide array of demanding industrial environments.
| Dimensions | ASTM, ASME and API |
| Thickness | 50mm to 7.00mm, custom OD and thickness available on request |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Required Length, Custom Size – according to customer’s requirement |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Types | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter | 19.05mm to 127mm |
| Wall Thickness | 0.8mm to 6.0mm |
| Length | 6mtr/ 12mtr or Cut to Length |
| Capacity | 7000 Mt/Month |
Grade | Mfg. Process | Chemical Composition(%) | ||||||||
C | Si | Mn | P | S | Ni | Cr | Mo | Others | ||
BW320 | B | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW320 | E | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW360 | E | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.050Max | – | – | – | – |
ERW430 | E | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | – |
S360 | S | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
S430 | S | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
SAW430 | A | 0.25Max | 0.50Max | 1.20Max | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
Grade
|
Tensile Test MPa or N/mm2 |
Remaks (Similar to JIS) |
Possibility Temperature |
|
|
Min Yield point |
Tensile Strength |
|||
|
BW320 |
195 |
320~460 |
– |
|
|
ERW320 |
195 |
320~460 |
– |
|
|
ERW360 |
235 |
360~500 |
(STPG370) |
|
|
ERW430 |
195 |
430~570 |
(STPG410) |
|
|
S360 |
235
225
215 |
360~550 |
(STPG310) |
|
|
S430 |
275
265
255 |
430~570 |
(STPG410) |
|
|
SAW430 |
275
265
255 |
430~570 |
(STPY400) |
|
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Nominal Pipe Size (inches) | Outer Diameter (mm) | Wall Thickness (mm) | Weight (kg/m) |
|---|---|---|---|
| 1/2 | 21.3 | 2.11 | 1.21 |
| 3/4 | 26.7 | 2.11 | 1.62 |
| 1 | 33.4 | 2.77 | 2.49 |
| 1 1/4 | 42.2 | 3.56 | 3.74 |
| 1 1/2 | 48.3 | 3.68 | 4.46 |
| 2 | 60.3 | 3.91 | 5.71 |
| 3 | 88.9 | 5.49 | 11.29 |
| 4 | 114.3 | 6.02 | 16.07 |
| 6 | 168.3 | 7.11 | 28.26 |
Jaxon Steel is a leading manufacturer and exporter of high-quality Carbon Steel BS3601 Pipes in Kinshasa, Congo. We offer a comprehensive range of steel solutions, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product portfolio includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliability and outstanding customer service, we are dedicated to delivering top-tier steel products designed for demanding industrial applications, ensuring long-lasting durability and superior performance. Jaxon Steel is your trusted partner for all Carbon Steel BS3601 Pipe needs.
You’ll find the Carbon Steel BS3601 Pipe hard at work in countless essential applications, forming the backbone of modern infrastructure. It’s the go-to choice for conveying water, oil, and gas in municipal and industrial pipeline systems, and is equally vital in structural frameworks for construction. From the scaffold on a building site to the utilities running beneath our streets, this pipe provides the silent, sturdy service that keeps projects moving forward and communities functioning smoothly.
